Key Attributes
Industry-specific Attributes
- Product Or Component Type auxiliary contact
- Range Of Product ComPact NS630b...1600
- [Ie] Rated Operational Current AC-12: 6 A at 690 V AC 50/60 Hz AC-12: 8 A at 240 V AC 50/60 Hz AC-12: 8 A at 380 V AC 50/60 Hz AC-12: 8 A at 480 V AC 50/60 Hz DC-12: 0.3 A at 250 V DC DC-12: 0.8 A at 125 V DC DC-12: 2.5 A at 24/48 V DC
- [Ue] Rated Operational Voltage AC-12: 6 A at 690 V AC 50/60 Hz AC-12: 8 A at 240 V AC 50/60 Hz AC-12: 8 A at 380 V AC 50/60 Hz AC-12: 8 A at 480 V AC 50/60 Hz DC-12: 0.3 A at 250 V DC DC-12: 0.8 A at 125 V DC DC-12: 2.5 A at 24/48 V DC
- Accessory / Separate Part Category spare part for ComPact NS630b...1600 spare part for Masterpact NT spare part for Masterpact NW spare part for Masterpact NW DC
- Device Short Name carriage switch
- EAN13 3303430331704
- Range Masterpact
- Range Compatibility ComPact NS630b...1600 MasterPact NT Masterpact NW Masterpact NW DC
Other Attributes
- Range Name ComPact NS NA
- Signal Contacts Composition 1 NO/NC
- Auxiliary Contacts Operation connected position disconnected position test position
- Auxiliary Contacts Type standard
- Device Application monitoring
- Minimum Load 100 mA at 24 V
- Mounting Mode drawout
- Poles Description auxiliary contact
