Key Attributes
Industry-specific Attributes
- Product name TeSys VARIO
- Device short name VCF
- Product or Component Type Enclosed emergency stop switch disconnector
- Performance level High performance
- Poles description 3P
- Control Type Rotary handle
- handle colour Red
- Handle front plate colour Yellow
- Rotary handle padlocking 1 to 3 padlocks 0.16…0.31 in (4…8 mm)
- Marking 0 - 1
- [Ue] rated operational voltage 690 V AC
- [Uimp] rated impulse withstand voltage 8 kV
Other Attributes
- [Ithe] conventional enclosed thermal current 16 A
- [Ie] rated operational current 11 A AC-23A)400 V
- Standards IEC 60947-4-1 IEC 60204
- Protective treatment TC
- IP degree of protection IP65 conforming to IEC 60529
- Mechanical robustness Vibrations 10...150 Hz 1 gn) IEC 60068-2-6 Shocks 11 ms 30 Gn) IEC 60068-2-27
- Ambient Air Temperature for Operation -4…122 °F (-20…50 °C)
- Category US10CP121730
- Returnability No
- Country of origin CZ
- handle front plate dimension 60 x 60 mm
- Fire resistance 1760 °F (960 °C) IEC 60595-2-1This TeSys VARIO enclosed switch disconnector supports three-pole motor applications up to 5.5 kW at 400 V AC-23. It features a robust rotary handle mechanism with position marking for easy identification of ON and OFF states.This TeSys VARIO enclosed switch disconnector supports three-pole motor applications up to 5.5 kW at 400 V AC-23. It features a robust rotary handle mechanism with position marking for easy identification of ON and OFF states.
